Lens |
: |
|
|
FOV |
: |
Horizontal field of view: 57.6° to 2.5° (Wide-Tele),Vertical field of view: 34.4° to 1.4° (Wide-Tele),Diagonal field of view: 64.5° to 2.9° (Wide-Tele) |
|
Zoom Speed |
: |
Approx. 3.6 s (optical lens, wide-tele) |
|
Working Distance |
: |
10 mm to 1500 mm (wide-tele) |
|
Aperture Range |
: |
F1.6 to F3.5 |
|
Focal Length |
: |
4.8 mm to 120 mm, 25× optical zoom |
|
Image |
: |
|
|
Image Enhancement |
: |
HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus |
|
Sub-Stream |
: |
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
|
Max. Resolution |
: |
1920 × 1080 |
|
Main Stream |
: |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),50fps (1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720),60fps (1280 × 960, 1280 × 720) |
|
Third Stream |
: |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
|
Network |
: |
|
|
Network Storage |
: |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
|
Protocols |
: |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
|
API |
: |
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform |
|
Simultaneous Live View |
: |
Up to 20 channels |
|
User/Host |
: |
Up to 32 users,3 levels: Administrator, Operator and User |
|
Client |
: |
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
|
Web Browser |
: |
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
|
Alarm Linkage |
: |
Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Trigger Recording, Trigger Alarm Output, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc. |
|
Interface |
: |
|
|
Alarm Output |
: |
1-ch alarm output |
|
Alarm Input |
: |
2-ch alarm input |
|
Audio Input |
: |
1-ch audio input, 2 to 2.4 V[p-p], 1 KΩ ± 10% |
|
Audio Output |
: |
1-ch audio output, line level, impedance: 600 Ω |
|
Network Interface |
: |
1 RJ45 10 M/100 M Ethernet, Hi-PoE |
|
Compression Standard |
: |
|
|
Video Compression |
: |
Main Stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG |
|
H.265 Type |
: |
Baseline Profile/Main Profile/High Profile |
|
Video Bitrate |
: |
32 Kbps to 16384 Kbps |
|
Audio Compression |
: |
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
|
Audio Bitrate |
: |
G.711alaw/G.711ulaw: 64 Kbps,G.722.1/G.726: 16 Kbps,MP212/PCM: 32 Kbps to 160 Kbps |
|
Camera Module |
: |
|
|
Image Sensor |
: |
1/2.8" progressive scan CMOS |
|
Min. Illumination |
: |
Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001Lux @(F1.6, AGC ON),0 Lux with IR |
|
White Balance |
: |
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
|
Gain |
: |
Auto/Manual |
|
Shutter Time |
: |
50Hz: 1/1 s to 1/30,000 s,60Hz: 1/1 s to 1/30,000 s |
|
Day & Night |
: |
IR Cut Filter |
|
Digital Zoom |
: |
16× |
|
Privacy Mask |
: |
24 programmable privacy masks |
|
Focus Mode |
: |
Auto/Semi-automatic/Manual |
|
WDR |
: |
120 dB WDR |
|
Supplement Light |
: |
|
|
IR Distance |
: |
150 m |
|
Smart IR |
: |
Support |
|
PTZ |
: |
|
|
Movement Range (Pan) |
: |
360° endless |
|
Pan Speed |
: |
Configurable, from 0.1°/s to 120°/s,Preset speed: 120°/s |
|
Movement Range |
: |
(Tilt) From -15° to 90° (auto-flip) |
|
Tilt Speed |
: |
Configurable, from 0.1°/s to 80°/s,Preset Speed: 80°/s |
|
Proportional Zoom |
: |
Support |
|
Presets |
: |
300 |
|
Patrol Scan |
: |
8 patrols, up to 32 presets for each patrol |
|
Pattern Scan |
: |
4 pattern scans, record time over 10 minutes for each scan |
|
Power-off Memory |
: |
Support |
|
Park Action |
: |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
|
3D Positioning |
: |
Support |
|
PTZ Status Display |
: |
Support |
|
Preset Freezing |
: |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output |
|
Smart Features |
: |
|
|
Basic Event Detection |
: |
Motion Detection, Video Tampering Detection, Exception |
|
Smart Detection |
: |
Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection |
|
Smart Record |
: |
ANR (Automatic Network Replenishment), Dual-VCA |
|
ROI |
: |
Main stream, sub-stream, and third stream respectively support four fixed areas. |
|
General |
: |
|
|
Material |
: |
ADC 12, PC, PC+10% GF |
|
Dimensions |
: |
Φ 208 mm × 345 mm |
|
Weight |
: |
Approx. 3.3 kg |
|
Protection |
: |
IP66 Standard, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
|
Power |
: |
24 VAC and Hi-PoE,Max.: 30 W (Max. 10 W for IR) |
|
Code |
: |
PCC-208 |
