Camera |
: |
|
|
Image Sensor |
: |
1/2.8" Progressive Scan CMOS |
|
Max. Resolution |
: |
1920 × 1080 |
|
Min. Illumination |
: |
Color: 0.0035 Lux @ (F1.0, AGC ON), B/W: 0 Lux with Light |
|
Shutter Time |
: |
1/3 s to 1/100,000 s |
|
Wide Dynamic Range |
: |
120 dB |
|
Angle Adjustment |
: |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
|
Lens |
: |
|
|
Focus |
: |
Fixed |
|
Lens Type |
: |
Fixed focal lens, 2.8, 4, and 6 mm optional |
|
FOV |
: |
2.8 mm, horizontal FOV: 112°, vertical FOV: 57°, diagonal FOV: 138°; 4 mm, horizontal FOV: 89°, vertical FOV: 46°, diagonal FOV: 106°; 6 mm, horizontal FOV: 56°, vertical FOV: 30°, diagonal FOV: 66° |
|
Lens Mount |
: |
M16 |
|
Aperture |
: |
F1.0 |
|
Illuminator |
: |
|
|
Supplement Light Range |
: |
Warm white LEDs (3000K), up to 30m |
|
Image |
: |
|
|
Image Settings |
: |
Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
|
Day/Night Mode |
: |
Day/Night |
|
Image Enhancement |
: |
BLC/3D DNR/HLC |
|
Video |
: |
|
|
Main Stream |
: |
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
|
Sub-Stream |
: |
50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) |
|
Third Stream |
: |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288) 60 Hz: 30 fps(1920 × 1080, 1280 × 720, 640 × 360, 352 × 240) |
|
Video Compression |
: |
Main stream: H.265+/H.265/H.264+//H.264; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264 |
|
Video Bit Rate |
: |
32 Kbps to 16 Mbps |
|
H.264 Type |
: |
Main Profile/High Profile |
|
H.265 Type |
: |
Main Profile |
|
Nework |
: |
|
|
Protocols |
: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
|
Simultaneous Live View |
: |
Up to 6 channels |
|
API ONVIF (PROFILE S, PROFILE G), ISAPI |
: |
|
|
User/Host |
: |
Up to 32 users, 3 levels: Administrator, Operator and User |
|
Client |
: |
iVMS-4200, Hik-Connect, iVMS-4500, iVMS-5200 |
|
Web Browser |
: |
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11; Plug-in free live view: Chrome 45.0+, Firefox 52.0+ |
|
Interface |
: |
|
|
Ethernet Interface |
: |
1 RJ45 10M/100M self-adaptive Ethernet port |
|
On-Board Storage |
: |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
|
Audio |
: |
1 audio input (built-in mic), mono sound |
|
Reset Key |
: |
Yes |
|
Event |
: |
|
|
Smart Event |
: |
Line crossing detection, intrusion detection, object removal detection, unattended baggage detection |
|
Face Detection |
: |
Yes |
|
Exception Detection |
: |
Scene change detection |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25%, Φ 5.5 mm coaxial power plug,PoE (802.3af, class 3) |
|
Dimension |
: |
Φ 138.3 × 125.2 mm |
|
Weight |
: |
575 g |
|
Approval |
: |
|
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-294 |
