Camera |
: |
|
|
Image Sensor |
: |
2 MP CMOS |
|
Max. Resolution |
: |
1920 (H) × 1080 (V) |
|
Min. Illumination |
: |
Color: 0.003 Lux @ (F1.87, AGC ON), 0 Lux with IR |
|
Shutter Time |
: |
PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
|
Day & Night |
: |
ICR |
|
Angle Adjustment |
: |
Pan: 0° to 340°, Tilt: 0° to 75°, Rotate: 0° to 355° |
|
Signal System |
: |
PAL/NTSC |
|
Lens |
: |
|
|
Lens Type |
: |
2.7 mm to 13.5 mm motorized, auto focus |
|
Focal Length & FOV |
: |
103° to 32.1° |
|
Lens Mount |
: |
Φ14 |
|
Image |
: |
|
|
Image Parameters Switch |
: |
STD/HIGH-SAT |
|
Image Settings |
: |
Brightness, Sharpness, Mirror, Smart IR |
|
Day/Night Mode |
: |
Auto/Color/BW (Black and White) |
|
Wide Dynamic Range (WDR) |
: |
>130dB |
|
Image Enhancement |
: |
BLC, HLC |
|
White Balance |
: |
ATW/MANUAL |
|
Interface |
: |
|
|
Video Output |
: |
Switchable TVI/AHD/CVI/CVBS |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25% |
|
Material |
: |
Plastic |
|
Dimension |
: |
Φ 136 mm × 101.9 mm |
|
Weight |
: |
Approx. 400 g |
|
Approval |
: |
|
|
Protection |
: |
IK10 |
|
Code |
: |
PCC-244 |
