Megapixels |
: |
1080P. |
|
Image Sensor |
: |
1/2.7" CMOS image sensor. |
|
Image Pixels |
: |
1920 (H) x 1080 (V) = 2,073,600 (pixel). |
|
Scanning System |
: |
Progressive Scan. |
|
illumination |
: |
0.1 Lux at F1.4 (Low Light Mode) / 0 Lux with IR LED ON. |
|
Shutter Time |
: |
1/30s - 1/8000s. |
|
Lens |
: |
3 - 10.5 mm (zoom / focus motorized). |
|
Angle of View |
: |
91.2 degree - 25.5 degree(H), 68.4 degree - 19.1 degree(V), 114 degree - 31.9 degree(D). |
|
IR Radiant Distance |
: |
25M. |
|
Video Compression |
: |
H.264 , Motion JPEG. |
|
Frame Rates |
: |
30 fps @ 1920 x 1080. |
|
Video Streaming |
: |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast. |
|
Video Bitrate |
: |
128Kbps - 5Mbps. |
|
Sense Up+ |
: |
Yes. |
|
Auto Gain Control |
: |
36 dB Variable Gain. |
|
3D Noise Reduction |
: |
Off / 1 - 32 Selectable. |
|
2D WDR |
: |
Off / On. |
|
Privacy Masking |
: |
Off / On (4 zones). |
|
ePTZ & Digital Zoom |
: |
ePTZ & ROI supported. |
|
Alarm Function |
: |
Alarm / motion / tampering / face detection triggering recording into SD card; Image upload over FTP and E-mail by face / tampering / audio / motion detection. |
|
Network Interface |
: |
10Mbps / 100Mbps Base-T, RJ-45. |
|
Audio |
: |
Two-way Audio, G.711 / PCM. |
|
SD Card |
: |
Support Micro SD/SDHC card for circular recording (card is not included). |
|
IP Rating |
: |
IP67. |
|
Vandal Resistant Rating |
: |
IK10. |
|
Dimensions |
: |
145 x 130mm. |
|
Weight |
: |
1000g. |
|
Power Supply |
: |
DC12V, 10W / PoE, 11.2W |
|
Code |
: |
PCC6122-03 |
