Image Sensor |
: |
1/3" progressive scan CMOS |
|
Max. Resolution |
: |
1280 x 720 |
|
Min. Illumination |
: |
0.0043 lux @ (ƒ/2.5, AGC on), 0 lux with IR |
|
Shutter Time |
: |
1/60 sec. to 1/50,000 sec |
|
Day & Night |
: |
IR cut filter |
|
Angle Adjustment |
: |
Pan: 0° to 355°, tilt: 0° to 75°, rotation: 0° to 355° |
|
Signal System |
: |
NTSC |
|
Lens |
: |
|
|
Lens Type |
: |
3.6 mm, ƒ/2.5 (2.8 mm, 6 mm, 8 mm optional) |
|
Focal Length & FOV |
: |
71.43° (3.6 mm), 92.45° (2.8 mm), 46.9° (6 mm), 34.5° (8 mm) |
|
Lens Mount |
: |
M12 |
|
Image |
: |
|
|
Synchronization |
: |
Internal synchronization |
|
Frame Rate |
: |
720p @ 60 fps |
|
Day/Night Mode |
: |
IR cut filter |
|
Angle Adjustment |
: |
Pan: 0° to 355°, tilt: 0° to 75°, rotation: 0° to 355° |
|
HD Video Output |
: |
1 analog HD output |
|
CVBS Output |
: |
1 V p-p composite output (75 Ω/BNC) |
|
Interface |
: |
|
|
Automatic Exposure |
: |
Globe AE/DWDR |
|
D/N Mode |
: |
Color/BW/SMART IR |
|
White Balance |
: |
ATW, AWC-SET, indoor, outdoor, manual |
|
3D DNR |
: |
Low/middle/high/off |
|
Motion Detection |
: |
On/off, maximum 4 zones |
|
General |
: |
|
|
Power |
: |
12 VDC |
|
IR Range |
: |
Up to 65 feet |
|
Dimension |
: |
φ126.7 mm × 102.4 mm |
|
Weight |
: |
300 g |
|
Protection |
: |
IP66 |
|
Code |
: |
PCC-141 |
