Camera |
: |
|
|
Image Sensor |
: |
1/2.4" Progressive Scan CMOS |
|
Max. Resolution |
: |
3200 × 1800 |
|
Min. Illumination |
: |
Color: 0.003 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
|
Shutter Time |
: |
1/3 s to 1/100,000 s |
|
Day & Night |
: |
IR cut filter |
|
Angle Adjustment |
: |
Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355° |
|
Signal System |
: |
No |
|
Lens |
: |
|
|
Lens Type |
: |
Fixed focal lens, 2.8 and 4 mm optional |
|
Focal Length & FOV |
: |
2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°; 4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96° |
|
Lens Mount |
: |
M12 |
|
Iris Type |
: |
Fixed |
|
Aperture |
: |
F1.6 |
|
DORI |
: |
|
|
DORI |
: |
2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m; 4 mm: D: 115 m, O: 45 m, R: 23 m, I: 11 m |
|
Illuminator |
: |
|
|
Supplement Light Type |
: |
IR |
|
Supplement Light Range |
: |
Up to 30 m |
|
Smart Supplement Light |
: |
Yes |
|
IR Wavelength |
: |
850 nm |
|
Image |
: |
|
|
Image Parameters Switch |
: |
Yes |
|
Image Settings |
: |
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
|
Day/Night Mode |
: |
Day,Night,Auto,Schedule |
|
Wide Dynamic Range (WDR) |
: |
120 dB |
|
Image Enhancement |
: |
BLC,HLC,3D DNR |
|
Privacy Mask |
: |
4 programmable polygon privacy masks |
|
Video |
: |
|
|
Main Stream |
: |
50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
|
Sub-Stream |
: |
50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360) |
|
Third Stream |
: |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), *Third stream is supported under certain settings. |
|
Video Compression |
: |
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264 (*Third stream is supported under certain settings.) |
|
Video Bit Rate |
: |
32 Kbps to 16 Mbps |
|
H.264 Type |
: |
Baseline Profile,Main Profile,High Profile |
|
H.265 Type |
: |
Main Profile |
|
Nework |
: |
|
|
Protocols |
: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets, SRTP, SFTP |
|
Simultaneous Live View |
: |
Up to 6 channels |
|
API |
: |
Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK, ISUP |
|
User/Host |
: |
Up to 32 users 3 user levels: administrator, operator, and user |
|
Client |
: |
iVMS-4200,Hik-Connect,Hik-Central |
|
Web Browser |
: |
Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
|
Interface |
: |
|
|
Ethernet Interface |
: |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
On-Board Storage |
: |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
|
Built-in Microphone |
: |
-U: Yes |
|
Audio |
: |
1 input (line in), max. input amplitude: 3.3 vpp, input impedance:4.7 KΩ, interface type: non-equilibrium; 1 output (line out), max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound |
|
Alarm |
: |
1 input, 1 output (TTL: max. 12 VDC, 30 mA) |
|
Reset Key |
: |
Yes |
|
Event |
: |
|
|
Basic Event |
: |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception, alarm input and output (-S) |
|
Smart Event |
: |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)),Scene change detection |
|
Linkage |
: |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,trigger alarm output (-S), audible warning (-S) |
|
Face Capture |
: |
Yes |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W |
|
Material |
: |
Aluminum alloy body, bubble: plastic |
|
Dimension |
: |
150 mm × 150 mm × 141 mm |
|
Weight |
: |
Ø121.4 mm × 92.2 mm (Ø4.8" × 3.6") |
|
Communication |
: |
|
|
Approval |
: |
|
|
EMC |
: |
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, KC: KN32: 2015, KN35: 2015 |
|
Safety |
: |
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017 |
|
Environment |
: |
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
|
Protection |
: |
IP67: IEC 60529-2013,IK10: IEC 62262:2002 |
|
Code |
: |
PCC-309 |
