Camera |
: |
|
|
Image Sensor |
: |
1/3" Progressive Scan CMOS |
|
Max. Resolution |
: |
2560 × 1440 |
|
Min. Illumination |
: |
Color: 0.001 Lux @(F1.0, AGC ON), 0 Lux with white light |
|
Shutter Time |
: |
1/3 s to 1/100, 000 s |
|
Wide Dynamic Range |
: |
120 dB |
|
Angle Adjustment |
: |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
|
Lens |
: |
|
|
Focus |
: |
Fixed |
|
Focal Length & FOV |
: |
2.8 mm, horizontal FOV 96.5°, vertical FOV 50.8°, diagonal FOV 113.9° 4 mm, horizontal FOV 75.8°, vertical FOV 40.8°, diagonal FOV 89.1° |
|
Lens Mount |
: |
M12 |
|
Aperture |
: |
F1.0 |
|
DORI |
: |
|
|
DORI |
: |
2.8 mm, D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m 4 mm, D: 77.4 m, O: 30.7m, R: 15.5m, I: 7.7 m |
|
Illuminator |
: |
|
|
Supplement Light Range |
: |
Up to 30 m |
|
Smart Supplement Light |
: |
Yes |
|
Image |
: |
|
|
Image Settings |
: |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
|
Day/Night Mode |
: |
Day, Night, Auto, Schedule |
|
Image Enhancement BLC, 3D DNR |
: |
|
|
Video |
: |
|
|
Main Stream |
: |
50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720) |
|
Sub-Stream |
: |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
|
Video Compression |
: |
Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG |
|
Video Bit Rate |
: |
32 Kbps to 8 Mbps |
|
H.264 Type |
: |
Baseline Profile/Main Profile/High Profile |
|
H.265 Type |
: |
Main Profile |
|
Nework |
: |
|
|
Protocols |
: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
|
Simultaneous Live View |
: |
Up to 6 channels |
|
API |
: |
Open Network Video Interface, ISAPI |
|
User/Host |
: |
Up to 32 users. 3 levels: administrator, operator and user |
|
Client |
: |
iVMS-4200, Hik-Connect |
|
Web Browser |
: |
Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
|
Interface |
: |
|
|
Ethernet Interface |
: |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
On-Board Storage |
: |
Built-in memory card slot, support microSD card, up to 256 GB |
|
Built-in Microphone |
: |
Yes |
|
Reset Key |
: |
Yes |
|
Event |
: |
|
|
Basic Event |
: |
Motion detection, video tampering alarm, exception |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25% PoE: 802.3af, Class 3 |
|
Dimension |
: |
Ø76.6 mm × 164.4 mm |
|
Weight |
: |
Approx. 430 g |
|
Approval |
: |
|
|
EMC |
: |
FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015) |
|
Safety |
: |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
|
Environment |
: |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
|
Protection |
: |
IP67 (IEC 60529-2013) |
|
Code |
: |
PCC-298 |
