Pick up device |
: |
1/3" SONY CMOS : 1.3 Mega |
|
Resolution |
: |
1280(H) x 720(V) @ 30FPS |
|
Lens Type |
: |
Board Lens : 6mm |
|
Synchronization |
: |
Internal |
|
Scanning System |
: |
2:1 Interlace |
|
S/N Ratio |
: |
More than 55 dB(AGC OFF) |
|
Electronic Shutter |
: |
Auto 1 / 60 (1 / 50) ~ 1 / 50,000 sec / FLK |
|
Min. Illumination |
: |
0.04Lux ( F2.0 , AGC ON) |
|
Video Output |
: |
AHD or 1280H |
|
White light Distance |
: |
<30M |
|
White Light Trigger |
: |
8Lux |
|
Motion Detect Rrange |
: |
3M |
|
Motion Detect |
: |
Light change / Picture change |
|
PIR detect range |
: |
7M |
|
PIR detect |
: |
Temperature |
|
3-Axis |
: |
P-T-T (Pan-Tilt-Twist) |
|
IR Cut |
: |
Yes |
|
IR Distance |
: |
40M |
|
Video Output |
: |
1.0 Vp-p / 75 ohm composite |
|
Power Source |
: |
DC12V+10% / 1A |
|
Dimension |
: |
119(Diameter) x 85(D)mm |
|
Weatherproof |
: |
IP66 |
|
Coaxial Cable Transmition Distance |
: |
(3C/5C)300 / 500 M |
|
Twisted Cable Transmition Distance |
: |
300 M. |
|
Code |
: |
PCC-124 |
