CPU Socket Suport |
: |
Intel® Core™ Ultra 2, LGA1851 |
|
Chipset |
: |
Intel® B860 Chipset |
|
Memory |
: |
2 x DIMM slots, max. 128GB, DDR5 Supports up to 8800+MT/s (OC) |
|
Graphics |
: |
1 x HDMITM port |
|
Expansion Slots |
: |
Intel® Core™ Ultra Processors (Series 2) |
|
|
: |
1 x PCIe 4.0 x16 slot |
|
|
: |
Intel® B860 Chipset |
|
|
: |
2 x PCIe 4.0 x1 slots |
|
Storage |
: |
2 x M.2 slots |
|
|
: |
4 x SATA 6Gb/s ports |
|
Ethernet |
: |
1 x Realtek 2.5Gb Ethernet |
|
Wireless & Bluetooth |
: |
Wi-Fi 6 1x1 Wi-Fi 6 (802.11ax) + Bluetooth® v5.3 |
|
USB |
: |
Rear USB (Total 6 ports) |
|
|
: |
1 x USB 10Gbps port (1 x Type-A) |
|
|
: |
2 x USB 5Gbps ports (2 x Type-A) |
|
|
: |
3 x USB 2.0 ports (3 x Type-A)** |
|
|
: |
Front USB (Total 7 ports) |
|
|
: |
1 x USB 5Gbps connector (supports USB Type-C®)* |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
2 x USB 2.0 headers support 4 additional USB 2.0 ports** |
|
|
: |
USB Type-C® power delivery output: max. 5V/3A. |
|
|
: |
USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth. |
|
Audio |
: |
Realtek 7.1 Surround Sound High Definition Audio CODEC |
|
Back Panel I/O Ports |
: |
1 x USB 10Gbps port (1 x Type-A) |
|
|
: |
2 x USB 5Gbps ports (2 x Type-A) |
|
|
: |
3 x USB 2.0 ports (3 x Type-A) |
|
|
: |
1 x HDMITM port |
|
|
: |
1 x Wi-Fi module |
|
|
: |
1 x Realtek 2.5Gb Ethernet port |
|
|
: |
3 x Audio jacks |
|
Internal I/O Connectors |
: |
Fan and Cooling Related |
|
|
: |
1 x 4-pin CPU Fan header |
|
|
: |
2 x 4-pin Chassis Fan headers |
|
|
: |
Power Related |
|
|
: |
1 x 24-pin Main Power connector |
|
|
: |
1 x 8-pin +12V CPU Power connector |
|
|
: |
Storage Related |
|
|
: |
2 x M.2 slots (Key M) |
|
|
: |
4 x SATA 6Gb/s ports |
|
|
: |
USB |
|
|
: |
1 x USB 5Gbps connector (supports USB Type-C®) |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
2 x USB 2.0 headers support 4 additional USB 2.0 ports |
|
|
: |
Miscellaneous |
|
|
: |
3 x Addressable Gen2 headers |
|
|
: |
1 x Clear CMOS header |
|
|
: |
1 x COM Port header |
|
|
: |
1 x Front Panel Audio header (F_AUDIO) |
|
|
: |
1 x S/PDIF Out header |
|
|
: |
1 x SPI TPM header (14-1 pin) |
|
|
: |
1 x 10-1 pin Front Panel System header |
|
Special Features |
: |
ASUS 5X PROTECTION III |
|
|
: |
- DIGI+VRM |
|
|
: |
- LANGuard |
|
|
: |
- Overvoltage protection |
|
|
: |
- SafeSlot Core+ |
|
|
: |
- Stainless-steel back I/O |
|
|
: |
ASUS Q-Design |
|
|
: |
- M.2 Q-Latch |
|
|
: |
- PCIe Slot Q-Release |
|
|
: |
- Q-Dashboard |
|
|
: |
- Q-DIMM |
|
|
: |
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) |
|
|
: |
- Q-Slot |
|
|
: |
ASUS Thermal Solution |
|
|
: |
- M.2 heatsink |
|
|
: |
- VRM heatsinks design |
|
|
: |
ASUS EZ DIY |
|
|
: |
- ProCool |
|
|
: |
- Pre-mounted I/O shield |
|
|
: |
Aura Sync |
|
|
: |
- Addressable Gen2 headers |
|
BIOS |
: |
256(128+128) Mb Flash ROM, UEFI AMI BIOS |
|
Dimension |
: |
24.4cm x 22.2cm |
|
Form Factor |
: |
micro-ATX |
