CPU Socket Suport |
: |
Intel® Core™ Ultra 2, LGA1851 |
|
Chipset |
: |
Intel® Z890 Chipset |
|
Memory |
: |
4 x DIMM slots, max. 256GB, DDR5 Support up to 9066+MT/s (OC) |
|
Graphics |
: |
1 x Display, 1 x HDMI™, 2 x Intel® Thunderbolt™ 4 |
|
Expansion Slots |
: |
Intel® Core™ Ultra Processors (Series 2) |
|
|
: |
1 x PCIe 5.0 x16 slot |
|
|
: |
Intel® Z890 Chipset |
|
|
: |
1 x PCIe 4.0 x16 slot (supports x4 mode) |
|
Storage |
: |
5 x M.2 slots |
|
|
: |
4 x SATA 6Gb/s |
|
Ethernet |
: |
1 x Intel® 2.5Gb Ethernet |
|
Wireless & Bluetooth |
: |
Wi-Fi 7 2x2 Wi-Fi 7 (802.11be) + Bluetooth® v5.4 |
|
USB |
: |
Rear USB (Total 10 ports) |
|
|
: |
2 x Thunderbolt™ 4 ports (2 x USB Type-C®)* |
|
|
: |
6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®with up to 30W PD/PPS Fast-charge) |
|
|
: |
2 x USB 5Gbps ports (2 x Type-A |
|
|
: |
Front USB (Total 7 ports) |
|
|
: |
1 x USB 20Gbps connector (supports USB Type-C® )* |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
2 x USB 2.0 headers support 4 additional USB 2.0 ports |
|
|
: |
USB Type-C® power delivery output: max. 5V/3A |
|
|
: |
USB Type-C® power delivery output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A |
|
Audio |
: |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
|
Back Panel I/O Ports |
: |
2 x Thunderbolt™ 4 ports (2 x USB Type-C®)* |
|
|
: |
6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®with up to 30W PD/PPD Fast-charge) |
|
|
: |
2 x USB 5Gbps ports (2 x Type-A) |
|
|
: |
1 x DisplayPort |
|
|
: |
1 x HDMI™ port |
|
|
: |
1 x Wi-Fi module |
|
|
: |
1 x Intel® 2.5Gb Ethernet port |
|
|
: |
2 x Audio jacks |
|
|
: |
1 x Optical S/PDIF out port |
|
|
: |
1 x BIOS FlashBack™ button |
|
|
: |
1 x Clear CMOS button |
|
Internal I/O Connectors |
: |
Fan and Cooling Related |
|
|
: |
1 x 4-pin CPU Fan header |
|
|
: |
1 x 4-pin CPU OPT Fan header |
|
|
: |
1 x 4-pin AIO Pump header |
|
|
: |
5 x 4-pin Chassis Fan headers |
|
|
: |
Power Related |
|
|
: |
1 x 24-pin Main Power connector |
|
|
: |
2 x 8-pin +12V CPU Power connectors |
|
|
: |
Storage Related |
|
|
: |
5 x M.2 slots (Key M) |
|
|
: |
4 x SATA 6Gb/s ports |
|
|
: |
USB |
|
|
: |
1 x USB 20Gbps connector (supports USB Type-C® ) |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
2 x USB 2.0 headers support 4 additional USB 2.0 ports |
|
|
: |
Miscellaneous |
|
|
: |
3 x Addressable Gen 2 headers |
|
|
: |
1 x Chassis Intrusion header |
|
|
: |
1 x CPU Over voltage jumper |
|
|
: |
1 x Front Panel Audio header (F_AUDIO) |
|
|
: |
1 x Start button |
|
|
: |
1 x 10-1 pin Front System Panel header |
|
|
: |
1 x Thermal Sensor header |
|
|
: |
1 x Thunderbolt™ (USB4®) header |
|
Special Features |
: |
Extreme Engine Digi+ |
|
|
: |
- 5K Black metallic capacitors |
|
|
: |
ASUS Q-Design |
|
|
: |
- M.2 Q-Latch |
|
|
: |
- M.2 Q-Release |
|
|
: |
- M.2 Q-Slide |
|
|
: |
- PCIe Slot Q-Release Slim (with PCIe SafeSlot) |
|
|
: |
- Q-Antenna |
|
|
: |
- Q-Dashboard |
|
|
: |
- Q-DIMM- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) |
|
|
: |
- Q-SlotASUS |
|
|
: |
Thermal Solution |
|
|
: |
- M.2 heatsink backplate |
|
|
: |
- M.2 heatsink |
|
|
: |
ASUS EZ DIY |
|
|
: |
- BIOS FlashBack™ button |
|
|
: |
- BIOS FlashBack™ LED |
|
|
: |
- Clear CMOS button |
|
|
: |
- CPU Socket lever protector |
|
|
: |
- ProCool II |
|
|
: |
- Pre-mounted I/O shield |
|
|
: |
- SafeSlot |
|
|
: |
- SafeDIMM |
|
|
: |
Aura Sync |
|
|
: |
- Addressable Gen 2 headers |
|
BIOS |
: |
256 Mb UEFI AMI BIOS |
|
Dimension |
: |
30.5 cm x 24.4 cm |
|
Form Factor |
: |
ATX |
|
