Camera |
: |
|
|
Image Sensor |
: |
1/2.9" Progressive Scan CMOS |
|
Max. Resolution |
: |
2944 × 1656 |
|
Day & Night |
: |
IR cut filter |
|
Min. Illumination |
: |
Color: 0.01 Lux @(F1.2; AGC ON), 0.028 Lux @(F2.0; AGC ON), 0 lux with IR |
|
Shutter Time |
: |
1/3 s to 1/100,000 s |
|
Wide Dynamic Range |
: |
120dB |
|
Angle Adjustment |
: |
Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360° |
|
Lens |
: |
|
|
Focus |
: |
Fixed |
|
Lens Type |
: |
2.8/4/6/8/12 mm |
|
FOV |
: |
2.8 mm, horizontal field of view: 97°,4 mm, horizontal field of view: 78°,6 mm, horizontal field of view: 60°,8 mm, horizontal field of view: 39.5°,12 mm, horizontal field of view: 19° |
|
Lens Mount |
: |
M12 |
|
Aperture |
: |
Fixed |
|
Illuminator |
: |
|
|
IR Range |
: |
up to 50 m,-I8: up to 80 m |
|
Image |
: |
|
|
Image Settings |
: |
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
|
Day/Night Mode |
: |
Day/Night/Auto/Schedule |
|
DNR |
: |
3D DNR |
|
Image Enhancement |
: |
BLC/3D DNR/HLC |
|
Video |
: |
|
|
Main Stream |
: |
50Hz: 20 fps (2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720),60Hz: 20 fps (2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
|
Sub-Stream |
: |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
|
Third Stream |
: |
50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288),60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240) |
|
Video Compression |
: |
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264 |
|
Video Bit Rate |
: |
32 Kbps to 16 Mbps |
|
H.264 Type |
: |
Main Profile/High Profile |
|
H.265 Type |
: |
Main Profile |
|
Nework |
: |
|
|
Protocols |
: |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
|
Simultaneous Live View |
: |
Up to 6 channels |
|
API |
: |
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome |
|
User/Host |
: |
Up to 32 users,3 levels: Administrator, Operator and User |
|
Client |
: |
iVMS-4200, Hik-Connect, Hik-Central |
|
Web Browser |
: |
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+ |
|
Alarm Trigger |
: |
Motion Detection, Tampering Alarm, Network Disconnected, IP Address Conflict, Illegal Login, HDD full, HDD error |
|
Interface |
: |
|
|
Ethernet Interface |
: |
1 RJ45 10M/100M self-adaptive Ethernet port |
|
On-Board Storage |
: |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
|
Reset Key |
: |
Yes |
|
Event |
: |
|
|
Basic Event |
: |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
|
Face Detection |
: |
Yes |
|
Exception Detection |
: |
Scene change detection |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25%, PoE(802.3af 36 to 57V, class 3) |
|
Dimension |
: |
Φ104.8 × 299.7 mm |
|
Weight |
: |
1200 g |
|
Approval |
: |
|
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-227 |
