Camera |
: |
|
|
Image Sensor 2 MP CMOS |
: |
|
|
Max. Resolution 1920 (H) × 1080 (V) |
: |
|
|
Min. Illumination 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
: |
|
|
Shutter Time PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
: |
|
|
Day & Night ICR |
: |
|
|
Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360° |
: |
|
|
Signal System PAL/NTSC |
: |
|
|
Lens |
: |
|
|
Lens Type 2.8 mm, 3.6 mm, 6 mm fixed lens |
: |
|
|
Focal Length & FOV 2.8 mm, horizontal FOV: 106.4°, vertical FOV: 57.9°, diagonal FOV: 124.6° 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8 |
: |
|
|
Lens Mount M12 |
: |
|
|
Image |
: |
|
|
Image Parameters Switch STD/HIGH-SAT |
: |
|
|
Image Settings Brightness, Sharpness, Mirror, Smart IR |
: |
|
|
Frame Rate TVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC |
: |
|
|
Day/Night Mode Auto/Color/BW (Black and White) |
: |
|
|
Wide Dynamic Range (WDR) Digital WDR |
: |
|
|
Image Enhancement Yes |
: |
|
|
White Balance Auto/Manual |
: |
|
|
Interface |
: |
|
|
Video Output Switchable TVI/AHD/CVI/CVBS |
: |
|
|
General |
: |
|
|
Power |
: |
12 VDC ± 25% |
|
Material |
: |
Plastic |
|
Dimension |
: |
58 mm × 61 mm × 158.6 mm |
|
Weight |
: |
Approx. 160 g |
|
Communication |
: |
HIKVISION-C |
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-257 |
