Projection System |
: |
LCD |
|
Native Resolution |
: |
WXGA (1280 x 800) pixels |
|
Lamp Light(lumens) |
: |
4,000 lm |
|
Lamp Life |
: |
NORMAL: 5,000 hours / ECO: 7,000 hours |
|
Contrast Ratio |
: |
"20,000:1 1 (Full On/Off) (input signals: PC, lamp power: NORMAL, picture mode: Dynamic, |
|
Iris: On, Daylight View: Off, Auto Power Save: Off )" |
: |
|
|
|
: |
|
|
Keystone Correction |
: |
Vertical: ±35° (±30° when using AUTO) (maximum value of WXGA input) Horizontal: ±35° (maximum value of WXGA input) |
|
Screen Size |
: |
0.76 - 7.62 m, 16:10 aspect ratio |
|
Connectivity |
: |
2x HDMI In: HDMI 19-pin (compatible with HDCP, Deep Color), audio signal: linear PCM (sampling |
|
frequencies: 48 kHz, 44.1 kHz, 32 kHz) |
: |
|
|
|
: |
|
|
|
: |
2x COMPUTER IN: D-sub HD 15-pin (female) |
|
|
: |
1x Video In: Pin jack (Composite VIDEO) |
|
|
: |
2x Audio In: M3 x 1 (L-R x 1) |
|
|
: |
1x LAN: RJ-45 x 1 (for network connection, 10BASE-T/100BASE-TX, compliant with PJLink™) |
|
|
: |
1x Serial In: D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
|
|
: |
1x USB-Type A: Memory Viewer / Wireless Module (DC 5 V, max 500 mA) |
|
|
: |
1x USB-Type B: For USB Display |
|
Power Consumption |
: |
100 - 240 V: 320 W |
|
Speaker Output |
: |
10.0 W (monaural) |
|
Dimensions (WxDxH) |
: |
352 x 98*3 x 279.4*4 mm |
|
Weight |
: |
3.3 kg |
|
Code |
: |
LCDPJTPSN-08 |
