Camera |
: |
|
|
Image Sensor |
: |
1/3” progressive scan CMOS for 2.8 mm lens |
|
Signal System |
: |
PAL / NTSC |
|
Image Resolution |
: |
1930 (H) x 1088 (V) |
|
Min Illumination |
: |
0.01 lux @ (F1.2,AGC ON), 0 lux with IR |
|
Shutter Time |
: |
1/25 (1/30) s to 1/50,000 s |
|
Len |
: |
|
|
Synchronization |
: |
Internal synchronization |
|
HD Video Output |
: |
1 analog HD-TVI output |
|
Video Frame Rate |
: |
1080p @ 25 fps / 1080p @ 30 fps |
|
Lens Mount |
: |
M12 |
|
Day and Night |
: |
ICR |
|
Menu |
: |
|
|
Camera ID |
: |
On / off (0-255) |
|
D/N Mode |
: |
Color / BW / Auto / EXT |
|
White Balance |
: |
Auto / user / push / 8000 K / 6000 K / 4200 K / 3000 K |
|
Anti-Flicker |
: |
On / off |
|
Functions |
: |
Digital noise reduction, mirror |
|
General |
: |
|
|
Power Supply |
: |
12 VDC ± 15% |
|
IR Range |
: |
Up to 20 m |
|
Communication |
: |
Up-the-Coax Protocol: HIKVISION-C (HD-TVI output) |
|
Dimensions |
: |
Φ70 × 149.5 mm |
|
Weight |
: |
400 g |
|
Protection |
: |
IP66 |
|
Code |
: |
PCC-165 |
