Megapixels |
: |
1080P |
|
Image Sensor |
: |
1/2.7" CMOS image sensor |
|
Max. Image Pixels |
: |
1920 (H) x 1080 (V) = 2,073,600 (pixel) |
|
Scanning System |
: |
Progressive Scan |
|
Min. illumination |
: |
0.1 Lux at F1.4 (Low Light Mode) / 0 Lux with |
|
IR LED |
: |
ON |
|
Shutter Time |
: |
1/30s - 1/8000s |
|
Lens |
: |
3.3 - 12 mm |
|
Angle of View |
: |
79.3 degree - 29.8 degree(H), 59.4 degree - 22.4 degree(V), 99 degree - 37.3 degree(D) |
|
IR Radiant Distance |
: |
25M |
|
Video Compression |
: |
H.264 , Motion JPEG |
|
Frame Rates |
: |
30 fps @ 1920 x 1080 |
|
Video Streaming |
: |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
|
Video Bitrate |
: |
128Kbps - 5Mbps |
|
Sense Up+ |
: |
Yes |
|
Auto Gain Control |
: |
36 dB Variable Gain |
|
3D Noise Reduction |
: |
Off / 1 - 32 Selectable |
|
2D WDR |
: |
Off / On |
|
Privacy Masking |
: |
Off / On (4 zones) |
|
ePTZ & Digital Zoom |
: |
ePTZ & ROI supported |
|
Alarm Function |
: |
Image upload over FTP and E-mail by face / tampering / motion detection |
|
Network Interface |
: |
10Mbps / 100Mbps Base-T, RJ-45 |
|
IP Rating |
: |
IP66 |
|
Vandal Resistant Rating |
: |
IK7 |
|
Dimensions |
: |
130 x 115mm |
|
Weight |
: |
1000g |
|
Power Supply |
: |
DC12V, 9W / PoE, 10.2W |
|
Code |
: |
PCC-320-01 |
