CPU Socket Suport |
: |
Intel® Core™ Ultra 2, LGA1851 |
|
Chipset |
: |
Intel® B860 Chipset |
|
Memory |
: |
4 x DIMM slots, max. 256GB, DDR5 Support up to 8800+MT/s (OC) |
|
Graphics |
: |
1 x Display, 1 x HDMI™, 1 x USB Type-C 20Gbps |
|
Expansion Slots |
: |
Intel® CoreTM Ultra Processors(Series 2) |
|
|
: |
1 x PCIe 5.0 x16 slot |
|
|
: |
Intel® B860 Chipset |
|
|
: |
1 x PCIe 4.0 x4 slot |
|
Storage |
: |
3 x M.2 slots |
|
|
: |
4 x SATA 6Gb/s |
|
Ethernet |
: |
1 x Realtek 2.5Gb Ethernet |
|
Wireless & Bluetooth |
: |
Wi-Fi 7 2x2 Wi-Fi 7 (802.11be) + Bluetooth® v5.4 |
|
USB |
: |
Rear USB (Total 8 ports) |
|
|
: |
1 x USB 20Gbps port (1 x USB Type-C®) |
|
|
: |
2 x USB 10Gbps port (2 x Type-A) |
|
|
: |
4 x USB 5Gbps ports (4 x Type-A) |
|
|
: |
1 x USB 2.0 ports (1x Type-A) |
|
|
: |
Front USB (Total 5 ports) |
|
|
: |
1 x USB 10Gbps connector (supports USB Type-C®) |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
1 x USB 2.0 headers support 2 additional USB 2.0 ports |
|
|
: |
USB Type-C® power delivery output: max. 5V/3A |
|
Audio |
: |
Realtek 7.1 Surround Sound High Definition Audio CODEC |
|
Back Panel I/O Ports |
: |
1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode) |
|
|
: |
2 x USB 10Gbps port (2 x Type-A) |
|
|
: |
4 x USB 5Gbps ports (4 x Type-A) |
|
|
: |
1 x USB 2.0 port (1 x Type-A) |
|
|
: |
1 x DisplayPort |
|
|
: |
1 x HDMI™ port |
|
|
: |
1 x Wi-Fi Module |
|
|
: |
1 x Realtek 2.5Gb Ethernet port |
|
|
: |
5 x Audio jacks |
|
|
: |
1 x Optical S/PDIF out port |
|
Internal I/O Connectors |
: |
I/O Connectors Fan and Cooling related |
|
|
: |
1 x 4-pin CPU Fan header |
|
|
: |
1 x 4-pin CPU OPT Fan header |
|
|
: |
1 x 4-pin AIO Pump header |
|
|
: |
3 x 4-pin Chassis Fan headers |
|
|
: |
Power related |
|
|
: |
1 x 24-pin Main Power connector |
|
|
: |
2 x 8-pin +12V Power connectors |
|
|
: |
Storage related |
|
|
: |
3 x M.2 slots (Key M) |
|
|
: |
4 x SATA 6Gb/s ports |
|
|
: |
USB |
|
|
: |
1 x USB 10Gbps connector (supports USB Type-C® ) |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
1 x USB 2.0 header supports 2 additional USB 2.0 ports |
|
|
: |
Miscellaneous |
|
|
: |
3 x Addressable Gen 2 headers |
|
|
: |
1 x Clear CMOS header |
|
|
: |
1 x Chassis Intrusion header |
|
|
: |
1 x Front panel audio header (F_AUDIO) |
|
|
: |
1 x 10-1 pin Front System Panel header |
|
|
: |
1 x Thunderbolt™ (USB4®) header |
|
Special Features |
: |
ASUS Exclusive Software |
|
|
: |
Armoury Crate |
|
|
: |
- AURA Creator |
|
|
: |
- AURA Sync |
|
|
: |
- Fan Xpert 2+ |
|
|
: |
- Power Saving |
|
|
: |
ASUS DriverHub |
|
|
: |
ASUS GlideX |
|
|
: |
TurboV Core |
|
|
: |
TUF GAMING CPU-Z |
|
|
: |
DTS Audio Processing |
|
|
: |
Norton 360 for Gamers (60 Days Free Trial) |
|
|
: |
WinRAR (40 Days Free Trial) |
|
|
: |
UEFI BIOS |
|
|
: |
ASUS EZ DIY |
|
|
: |
- ASUS CrashFree BIOS 3 |
|
|
: |
- ASUS EZ Flash |
|
|
: |
- ASUS UEFI BIOS EZ Mode |
|
|
: |
- ASUS MyHotkey |
|
|
: |
NPU Boost |
|
BIOS |
: |
2 x 128 Mb Flash ROM, UEFI AMI BIOS |
|
Dimension |
: |
24.4 cm x 24.4 cm |
|
Form Factor |
: |
mATX |
