Camera |
: |
|
|
Image Sensor |
: |
2MP CMOS |
|
Max. Resolution |
: |
1920 (H) × 1080 (V) |
|
Day & Night |
: |
ICR |
|
Min. Illumination |
: |
0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
|
Shutter Time |
: |
PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
|
Frame Rate |
: |
TVI: 1080P@30fps, 1080P@25fps |
|
Signal System |
: |
PAL/NTSC |
|
Lens |
: |
|
|
Lens Type |
: |
2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens |
|
Focal Length & FOV |
: |
2.8 mm, horizontal FOV: 101°, vertical FOV: 60°, diagonal FOV: 122° 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8° 8 mm, horizontal FOV: 39.9°, vertical FOV: 21.9°, diagonal FOV: 46.5° 12 mm, horizontal FOV: 24.6°, vertical FOV: 13.9°, diagonal FOV: 28.1° |
|
Lens Mount |
: |
M12 |
|
Angle Adjustment |
: |
Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360° |
|
Image |
: |
|
|
Image Mode |
: |
STD/HIGH-SAT |
|
Function |
: |
Brightness, Sharpness, Smart IR |
|
Day/Night Mode |
: |
Auto/Color/BW (Black and White |
|
Noise Reduction |
: |
2D DNR |
|
White Balance |
: |
Auto/Manual |
|
Interface |
: |
|
|
Video Output |
: |
1 HD analog output |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25% |
|
Material |
: |
Front Cover: Metal Main Body: Plastic |
|
Dimension |
: |
75.4 mm × 78.9 mm × 187.1 mm |
|
Weight |
: |
Approx. 305 g |
|
Approval |
: |
|
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-252 |
