Camera |
: |
|
|
Image Sensor |
: |
1/3” Progressive Scan CMOS |
|
Max. Resolution |
: |
1920 x 1080 |
|
Min. Illumination |
: |
0.07Lux @F1.2, AGC ON, 0 lux with IR |
|
Shutter Time |
: |
1/3s ~ 1/100,100s |
|
Day & Night |
: |
IR cut filter with auto switch |
|
Angle Adjustment |
: |
Pan: 0° ~ 355°, Tilt: 0° ~ 65°, Rotation: 0 ~ 360° |
|
Digital noise reduction |
: |
3D DNR |
|
Wide dynamic range |
: |
Digital WDR |
|
Lens |
: |
|
|
Lens Type |
: |
4mm @ F2.0, (2.8mm, 6mm optional) Angle of view: 98.5°(2.8mm), 79°(4mm), 49°(6mm) |
|
Angle adjustment |
: |
Pan: 0° ~ 355°, Tilt: 0° ~ 65°, Rotation: 0 ~ 360° |
|
Lens Mount |
: |
M12 |
|
Image |
: |
|
|
Image settings |
: |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
Frame Rate |
: |
50Hz: 25fps (1920 × 1080), 25fps (1280 x 720) 60Hz: 30fps (1920 × 1080), 30fps (1280 x 720) |
|
Day/Night Mode |
: |
IR cut filter with auto switch |
|
Angle Adjustment |
: |
Pan: 0° ~ 355°, Tilt: 0° ~ 65°, Rotation: 0 ~ 360° |
|
BLC |
: |
Yes, zone configurable |
|
ROI |
: |
Yes, up to 3 configurable areas |
|
Interface |
: |
|
|
Communication Interface |
: |
1 RJ45 10M/100M Ethernet interface |
|
Network |
: |
|
|
Protocols |
: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
|
Alarm trigger |
: |
Intrusion detection, Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage full, Storage error |
|
Network storage |
: |
Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB ; NAS |
|
General functionalities |
: |
User Authentication, Watermark |
|
WiFi |
: |
|
|
Wireless Standards |
: |
IEEE802.11b, 802.11g, 802.11n Draft |
|
Frequency Range |
: |
2.4 GHz ~ 2.4835 GHz |
|
Channel Bandwidth |
: |
20/40MHz Support |
|
Transfer Rates |
: |
11b: 11Mbps ; 11g: 54Mbps ; 11n: up to 150Mbps |
|
Wireless Range |
: |
Outdoor: 200m, Indoor: 50m ; *The performance varies based on actual environment. |
|
General |
: |
|
|
Power |
: |
12 V DC ± 10% ; PoE (802.3af) |
|
IR Range |
: |
30 meters |
|
Dimension |
: |
Φ111 × 82 |
|
Weight |
: |
500g |
|
Protection |
: |
IP66 |
|
Code |
: |
PCC-178 |
